General |
Device type | Power distribution unit - rack-mountable |
Height rack units | 0U |
Cord length | 3.05 m |
Colour | Black |
Power device |
Input voltage | AC 200-240 V |
Input wiring | 1-phase |
Frequency required | 50/60 Hz |
Input connectors | 1 x power IEC 60309 32A |
Power output connectors details | 21 x power IEC 60320 C13 3 x power IEC 60320 C19 |
Output voltage | AC 200-240 V |
Max electric current | 32 A |
Circuit protection | Circuit breaker |
Networking |
Remote management interface | Ethernet, serial |
Remote management protocol | SNMP 1, Telnet, SNMP 3, HTTP, SSH, SMTP, NTP |
Expansion connectivity |
Interfaces | 1 x LAN - RJ-45 1 x serial - RJ-45 1 x sensor - RJ-45 1 x USB - 4 pin USB Type A 1 x cascading - RJ-45 |
Miscellaneous |
Cables included | Power cable 3.05 m Serial cable - external |
Features | Vertical orientation, LCD display, voltage monitoring, current meter, over current protection, overload protection, digital power meter, AC frequency monitoring, firmware upgradable |
Compliant standards | RoHS, EN 55032 Class A |
Software system requirements |
Software included | PowerPanel Business Edition |
Manufacturer warranty |
Service support | Limited warranty - 3 years |
Environmental parameters |
Min operating temperature | 0 °C |
Max operating temperature | 55 °C |
Humidity range operating | 0 - 95% (non-condensing) |
Dimensions weight |
Width | 5.6 cm |
Depth | 4.8 cm |
Height | 166.5 cm |
Weight | 8 kg |
Dimensions weight shipping |
Shipping width | 18.5 cm |
Shipping depth | 11.5 cm |
Shipping height | 189.5 cm |
Shipping weight | 9.9 kg |
