General |
Device type | UPS - external |
Power device |
Input voltage | AC 230 V |
Input voltage range | AC 165 - 265 V |
Frequency provided | 50/60 Hz |
Frequency required | 47 - 63 Hz |
Input connectors | 1 x power IEC 60320 C14 |
Power output connectors details | 6 x power CEE 7/4 (UPS and surge) |
Output voltage | AC 230 V ± 10% - 50/60 Hz |
Power capacity | 540 Watt / 900 VA |
Dataline surge protection | Network/phone line - RJ-45/RJ-11 - 1 input line / 1 output line |
Output waveform | Sinewave |
Circuit protection | Circuit breaker |
Battery |
Quantity | 1 |
Technology | Lead Acid |
Voltage provided | 12 V |
Capacity | 8.5 Ah |
Recharge time | 8 hours |
Networking |
Remote management interface | USB |
Expansion connectivity |
Interfaces | 1 x management (USB) - 4 pin USB Type B |
Miscellaneous |
Equipment protection value | 50000 Euros |
Features | Audible alarm, LCD display, Automatic Voltage Regulation (AVR), GreenPower UPS Technology, overload protection |
Compliant standards | RoHS |
Software system requirements |
Software included | PowerPanel Personal |
Manufacturer warranty |
Service support | Limited warranty - 2 years |
Environmental parameters |
Min operating temperature | 0 °C |
Max operating temperature | 40 °C |
Humidity range operating | 0 - 95% (non-condensing) |
Dimensions weight |
Width | 10 cm |
Depth | 27.5 cm |
Height | 23 cm |
Weight | 7.1 kg |
